Heavy Load Optional DC Motor Coil Electrical Track Transfer Cart
試供品およびクーポンのための私に連絡しなさい。
whatsapp:0086 18588475571
WeChat: 0086 18588475571
Skype: sales10@aixton.com
心配があれば、私達は24時間のオンライン・ヘルプを提供する。
x商品の詳細
| 色 | カスタマイズ | 製品名 | 柔軟な電池用シザーの空中作業プラットフォーム |
|---|---|---|---|
| 負荷容量 | カスタマイズ | 電源 | バッテリー動作 |
| ポート | 清dao/Tianjin/Shanghai | 応用 | 重工業、屋外、建設 |
| 材料 | 鋼鉄 |
製品の説明
Heavy Load Optional DC Motor Coil Electrical Track Transfer Cart
Product Description
Strong Load Capacity
Heavy loads are our core competence. Whether it's steel, large machinery, or automotive parts, we offer solutions for loads ranging from a few tons to hundreds of tons, tailored to your needs and ensuring safe transportation.
Flexible Power Options
Optional DC Motors: We offer the most suitable power solution for you. DC motors are renowned for their excellent start-stop stability and speed regulation, enabling precise start-up control and stepless speed regulation, making them particularly suitable for applications requiring precise positioning.
Reliable Power Supply System
We have selected a battery-powered system. Safe and stable: Compared to busbar power supply, this system has no exposed contacts, eliminating the risk of short circuits and power outages caused by dust and metal shavings, making it particularly suitable for harsh, dusty, and humid environments.
Easy Maintenance: The track structure is sturdy, and the power coils are buried within, significantly reducing routine maintenance.
Long-Distance Operation: Ideal for assembly line operations requiring long-distance, continuous transport.
Product Parameter
| Model | KPT-2T | KPT-5T | KPT-10T | KPT-16T | KPT-20T | KPT-25T | KPT-30T | KPT-40T | KPT-50T | KPT-63T | KPT-80T | KPT-100T | KPT-150 | |
| Rated load(t) | 2 | 5 | 10 | 16 | 20 | 25 | 30 | 40 | 50 | 63 | 80 | 100 | 150 | |
| Table Size | Length(L) | 2000 | 3500 | 3600 | 4000 | 4000 | 4500 | 4500 | 5000 | 5500 | 5600 | 6000 | 6500 | 10000 |
| Width(W) | 1500 | 2000 | 2000 | 2000 | 2200 | 2200 | 2200 | 2500 | 2500 | 2500 | 2600 | 2800 | 3000 | |
| Heigth(H) | 500 | 550 | 550 | 600 | 600 | 650 | 650 | 700 | 700 | 800 | 900 | 1000 | 1200 | |
| Wheel Base(mm) | 1200 | 2500 | 2600 | 2800 | 2800 | 3200 | 3200 | 3800 | 4200 | 4300 | 4700 | 4900 | 7000 | |
| Rai Ilnner Gauge(mm) | 1200 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1800 | 2000 | 2000 | |
| Wheel Dia.(mm) | Φ270 | Φ300 | Φ300 | Φ350 | Φ350 | Φ400 | Φ400 | Φ500 | Φ500 | Φ600 | Φ600 | Φ600 | Φ600 | |
| Wheel Quantity(pcs) | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 8 | |
| Ground Clearance(mm) | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 75 | 75 | 75 | 75 | |
| Running Speed(mm) | 25 | 25 | 25 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 18 | |
| Motor Power(kw) | 0.8 | 1.5 | 1.5 | 2.2 | 2.5 | 3 | 4 | 5.5 | 5.5 | 7.5 | 7.5 | 11 | 15 | |
| Running distance(m) | 25 | 25 | 25 | 25 | 30 | 30 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | |
| Max Wheel load(KN) | 14.4 | 25.8 | 42.6 | 64.5 | 77.7 | 94.5 | 110.4 | 142.8 | 174 | 221.4 | 278.4 | 343.8 | 265.2 | |
| Reference Wight(t) | 2.5 | 3.5 | 4 | 5.2 | 5.6 | 6.2 | 6.5 | 7.3 | 7.8 | 10.5 | 12.3 | 14.1 | 26.2 | |
| Recommend Rail Model | P15 | P18 | P18 | P24 | P24 | P38 | P38 | P43 | P43 | P50 | P50 | QU100 |
QU100 |
|
Company Profile
Xinxiang Hundred Percent Electrical And Mechanical Co., Ltd. is a professional and international handling equipment company integrating R&D, design, production and sales. It has a modern management team, technical team and production technician team.
Founded in September 2003, the company is located in Xinxiang city, Henan province, covering an area of 33,300 square meters. It has a modern large-scale factory building, world-advanced production equipment and office equipment. The company has more than 150 employees, including 8 engineers and more than 20 technicians. The company has a first-class research and design team, which can undertake the design and production of various non-standard handling equipment.
BEFANBY can not only provide transfer cart quotations, but also provide you with satisfactory handling solutions.
Product Details
1. Fixed rail
Stable and controllable travel path, suitable for applications requiring repetitive single positioning (such as material distribution on production lines). Encoders or laser navigation can be added to enhance docking accuracy.
2. High Load Capacity
The load capacity can be customized (typically 1-100 tons) based on demand, making it suitable for handling heavy equipment (such as steel and molds).
3. Energy-Saving and Environmentally Friendly
Powered by batteries or low-voltage power (such as 36V/48V safe voltage), it produces no exhaust emissions and is suitable for indoor environments, aligning with green environmental development.
4. Automation Integration
Can be integrated with PLC, AGV systems, or MES systems for automated scheduling, reducing manual intervention. Optional remote control or intelligent obstacle avoidance features are available.
5. High Safety
Equipped with protective devices such as limit switches, anti-collision buffers, and an emergency stop mechanism.
6. Long Life and Low Maintenance
Simple structure and non-slip, wear-resistant cast steel wheels require only regular inspection of the rail and motor.
Product Feature
Shipping
Related Products
FAQ
1) Q: How can I operate the transfer cart ?
A: Please don't worry, dear friend. The English user manual, parts manual will be delivered with your items together.
2) Q: How to ensure your product quality ?
A : We will free provide rail installation drawing, rail foundation construction drawing, free technical guide. And if necessary,our installation engineer will go to your factory to guide the installation.
3)Q: Whether you can offer customized transfer car?
A: Yep, of course, we are manufacturer, and we have our own engineer group. They can work out customized design according to your requirement. The most important thing is that you tell us what you need.
4)Q: Whether there is professional technician assist our installation?
A :Yep. We have professional installation team, who have gone to many countries to assist the installation. If you need we send technician to your factory, please let us know in advance. So that we can arrange technicians.
Product Tap: Material Handling Cart , Rail Transfer Cart
